The HD-EM0802-LW15-R is a reliable 8 mm ERM haptic vibration motor optimized for low-power, high-performance applications. Operating within a 2.6–3.6 VDC range, this motor delivers 12,000 RPM with just 85 mA current draw. Engineered with durability in mind, it passes extensive reliability testing, including drop, vibration, and life-cycle endurance. A versatile solution for handheld electronics, medical devices, and feedback systems requiring consistent performance.

Technical Highlights

  • Rated Voltage: 3.0 VDC

  • Speed: 12,000 ± 2,500 RPM

  • Current Draw: 85 mA @ 3 VDC

  • Noise: ≤ 50 dBA

  • Operating Temp: -20 ~ +60 °C

  • Storage Temp: -30 ~ +70 °C

  • Weight: 1 g

Unit of Measure

Height

 N/A 2 mm

Width

 N/A 8 mm

Length

 N/A 8 mm

Operating Temperature

 N/A -20 ~ +60 ºC

Device Type

 N/A ERM

Terminal / Mounting

 N/A Lead Wires

Rated Voltage

 N/A 3 V

Voltage Minimum

 N/A 2.6

Terminal Resistance

 N/A 32 Ω

Current Draw

 N/A 85 mA

Rated Speed

 N/A 12000 rpm

Voltage Maximum

 N/A 3.6

Tolerance (±)

 N/A 20 %

Weight

 N/A 1 g
