Height	N/A 5.8 mm
Width	N/A 5.1 mm
Length	N/A 11.8 mm
Operating Temperature	N/A -20 ~ +60 ºC
Device Type	N/A ERM
Terminal / Mounting	N/A Spring Contacts
Rated Voltage	N/A 3 V
Voltage Minimum	N/A 2.4
Terminal Resistance	N/A 30 Ω
Current Draw	N/A 90 mA
Rated Speed	N/A 12000 rpm
Voltage Maximum	N/A 3.6
Tolerance (±)	N/A 20 %
Weight	N/A 1 g
